AirFlex® OVERLAY
2 Cell-Cycle Alternating Pressure Mattress Overlay
AirFlex® OVERLAY is a high quality, cost effective, 2-cell cycle alternating pressure overlay mattress which provides excellent pressure relief, especially when placed on top of a high specification foam pressure relieving mattress. It is a large cell, dynamic overlay designed to provide the changes in interface pressure required to stimulate reactive hyperaemia in the deep tissues surrounding the bony prominences.
The mattress has in-built pressure sensors that automatically adjust to a patient’s weight and changes in body position. It also features advanced engineering and a quality compressor that provides therapeutic treatment for patients weighing from 30 to 180 kg. The AirFlex® OVERLAY is fully automatic and recommended for the prevention of pressure injuries in high risk patients and especially those in long-term care.
AirFlex® OVERLAY is part of the new innovative ‘cost effective’ range of mattress solutions designed to fulfil the requirements of ‘affordable healthcare.’
- Product Sheet:
- Product Sheet - English
Patient Safety and Comfort
- 10 minute alternating pressure 2 cell-cycle provides effective pressure variation through continuous cell inflation/deflation
- Low interface pressures for maximum patient comfort
- Dual pressure settings improve comfort for frail and underweight patients without compromising pressure relief
- Fully automatic adjustment to patient’s weight and body position
Additional Nursing Support
- Audible and visual alarms provide peace of mind for nursing staff
- Rapid deflation on release of CPR connector
- Dual comfort settings within both Static and Dynamic modes
- Static mode defaults to Alternating mode after 30 minutes
- Static mode provides a firm and stable surface for essential nursing procedures such as physiotherapy, wound dressing and bed linen changes
- Transport mode ensures the mattress remains inflated for 8 hours in the event of a mains power failure
- V-Lock system prevents accidental disconnection of the power cord
Maximises Infection Control
- Waterproof, vapour permeable, Dartex® covers provide microclimate control at the skin/mattress interface
- Soft, smooth covers reduce shear and friction as well as allowing easy wipe down when cleaning
- Welded seams prevent the ingress of fluids into the mattress
- 360° zip ensures cover can be easily removed for infection control and high temperature laundering
- Generous waterfall flap protects zip and the integrity of the air-cells
| Technical Specification | |
| Number of cells | 18 |
| Mattress material | Cells: Polyurethane |
| Classification | Class B Medical Device / Class II |
| Mattress – flammability rating | Complies with BS7175 ignition source 0, 1 and 5 |
| Power unit – flammability rating / ingress protection | UL 94 V-0 / IP 42 |
| Power supply / power consumption | 230 V~ ±10%, 50 / 60 Hz 20 W max |
| Dimensions | |
| Mattress sizes | 1880 x 880 x 100 mm (standard) 1880 x 800 x 100 mm (narrow) |
| Max. patient weight | 180 kg |
| Pump unit dimensions | 400 x 160 x 250 mm |
| Mattress weight | 8.5 kg |
| Pump weight | 2.8 kg |
